Lightweight NEMA 11 Hybrid Stepper Motor Six Wire 4 Leads 1.2 Kg Cm 106 Oz In 28BYGH501

Place of Origin China
Brand Name HeTai
Certification CE ROHS ISO
Model Number 28BYGH
Minimum Order Quantity 50
Price USD
Packaging Details Carton with Inner Foam Box, Pallet
Delivery Time 25 DAYS
Payment Terms L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability 10000 PCS/MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Hybrid Stepping Motor Step Accuracy ± 5%
Temperature Rise 80 ℃ Max Insulation Resistance 100MΩ Min.500VC DC
Ambient Temperature -20℃~+50℃ Dielectric Strength 500VAC 1 Minute
Max Radial Force 28N (20mm From Front Flange) Max Axial Force 10N
Step Angle 1.8 ° No. Of Leads 4 Or 6
High Light

28BYGH501 Nema 11 Hybrid Stepper Motor

,

28BYGH501 six wire stepper motor 106 Oz In

,

lightweight stepper motor 28BYGH501

Leave a Message
Product Description

28BYGH series NEMA 11 lightweight micro 4 or 6 leads 1.2 kg.cm micro stepper motor



28 BYGH series is a type of micro DC stepper motor, has a step angle of 1.8 degrees and +/- step accuracy. The ambient temperature should be -20℃~+50℃. The temperature rise is 80 ℃ Max. The dielectric strength is 500VAC 1 minute.



Stepper motors are DC motors that move in discrete steps. They have multiple coils that are organized in groups called "phases". By energizing each phase in sequence, the motor will rotate, one step at a time.

Electrical Specification:



MODEL STEP ANGLE
(°/STEP)
 LEAD WIRE
(NO.)
VOLTAGE
(V)
CURRENT
(A/PHASE)
RESISTANCE
(Ω/PHASE)
INDUCTANCE
(MH/PHASE)
HOLDING TORQUE
(G.CM)
MOTOR HEIGHT
L(MM)
MOTOR WEIGHT
(KG)
28BYGH102-01 1.8 4 3.90 0.67 6.3 3.2 600 32 0.11
28BYGH105-01 1.8 6 3.1 0.95 3.3 1.0 430 32 0.11
28BYGH301 1.8 4 4.56 0.67 6.8 4.9 950 45 0.17
28BYGH303 1.8 6 3.40 0.95 3.4 1.0 750 45 0.14
28BYGH501 1.8 4 8.04 0.67 12.0 7.2 1200 51 0.19
28BYGH502 1.8 6 3.80 0.95 4.0 1.3 900 51 0.20

*Products can be customized by special request.

*Products can match gearbox 22.28 mm



Wiring Diagram

Lightweight NEMA 11 Hybrid Stepper Motor Six Wire 4 Leads 1.2 Kg Cm 106 Oz In 28BYGH501 0

Mechanical Dimension

Lightweight NEMA 11 Hybrid Stepper Motor Six Wire 4 Leads 1.2 Kg Cm 106 Oz In 28BYGH501 1



Construction & Working Principle

The construction of a stepper motor is fairly related to a DC motor. It includes a permanent magnet like Rotor which is in the middle & it will turn once force acts on it. This rotor is enclosed through a no. of the stator which is wound through a magnetic coil all over it. The stator is arranged near to rotor so that magnetic fields within the stators can control the movement of the rotor.
