24v 250w Nema 34 Brushless Dc Motor High Torque Low Speed

  • 24v 250w Nema 34 Brushless Dc Motor High Torque Low Speed
  • 24v 250w Nema 34 Brushless Dc Motor High Torque Low Speed
Place of Origin China
Brand Name HeTai
Certification CE ROHS ISO
Model Number 57BLF
Minimum Order Quantity 50
Price USD
Packaging Details Carton with Inner Foam Box, Pallet
Delivery Time 25 DAYS
Payment Terms L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability 10000 PCS/MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Brushless DC Motor Winding Type Star
Insulation Class B Ambient Temperature -20℃~+50℃
Hall Effect Angle 120° Electrical Angle Rated Speed 3800 Rpm
Insulation Resistance 100MΩ Min.500VC DC Dielectric Strength 600VAC 1 Minute
Max Radial Force 115N (10mm From Front Flange) Max Axial Force 45N
High Light

nema 34 bldc motor

,

24v 250w bldc motor

,

57blf motor
Leave a Message
Product Description

57BLF nema 34 high torque IP40 motor brushless DC 250W for robotic arms



57BLF01 3 phase 8 poles Voltage 24V, Rated current 3.33A, Rated torque 0.2 Nm

57BLF02 3 phase 8 poles Voltage 24V, Rated current 6.67A, Rated torque 0.4 Nm

57BLF03 3 phase 8 poles Voltage 24V, Rated current 10A, Rated torque 0.6 Nm

57BLF04-001 3 phase 8 poles Voltage 36V, Rated current 8.87A, Rated torque 0.8 Nm



Electrical Specification:

    Model Model Model Model
Specification Unit 57BLF01 57BLF02 57BLF03 57BLF04-001
Number Of Phases Phase 3
Number Of Poles Poles 8
Rated Voltage VDC 24 36
Rated Speed Rpm 3000 3000 3000 3000
Rated Current A 3.33 6.67 10.0 8.87
Rated Torque N.m 0.2 0.4 0.6 0.8
Rated Power W 80 125 188 251
Peak Torque N.m 0.6 1.2 1.8 2.4
Peak Current Amps 10.0 20.0 30.0 26.6
Torque Constant N.m/A 0.06 0.06 0.06 0.09
Back EMF constant V/kRPM 6.3 6.3 6.3 9.47
Body Length mm 59 80 101 122
Weight Kg 0.61 0.94 1.25 1.59



*Products can be customized by special request.

*Products can match gearbox 42, 52, 56, 63mm



Wiring Diagram

FUNCTION COLOR
+5V RED UL1007 26AWG
HALL A YELLOW
HALLB GREEN
HALLC BLUE
GND BLACK
PHASE A YELLOW UL1015 20AWG
PHASE B GREEN
PHASE C BLUE


Mechanical Dimension

24v 250w Nema 34 Brushless Dc Motor High Torque Low Speed 0



Changzhou Hetai Motors is an experienced motor manufacturer. For more than 20 years, Hetai dedicates to provide professional electrical integration design and automation strategies for customers. We have variable manufacturing equipment, such as assembly line, Automatic cylindrical grinder and CNC machining centers as well.24v 250w Nema 34 Brushless Dc Motor High Torque Low Speed 1
