Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm

Place of Origin China
Brand Name HeTai
Certification CE ROHS ISO
Model Number 57BYGHM203-04
Minimum Order Quantity 50
Price USD
Packaging Details Carton with Inner Foam Box, Pallet
Delivery Time 28-31 DAYS
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 5000 PCS/MONTH
Product Details
Product Name Hybrid Stepper Motor Step Angle 0.9 °
Lead Wire 6 Inductance 38mH
Holding Torque 5.5 Kg.cm Rated Voltage 12V
Rated Current 0.38A Resistance 32Ω
Motor Height 51 Mm Motor Weight 0.56 Kg
High Light

Nema23 Hybrid Micro Stepping Motor

,

57mm Micro Stepping Motor

,

57BYGHM203-04 Hybrid Stepper Motor

Leave a Message
Product Description

57mm Hetai 57BYGHM203-04 nema23 hybrid stepper motor factory supply micro stepping motor



Advantages of stepper motors
1. The angle of motor rotation is proportional to the number of pulses;
2. The motor has the maximum torque when it stops (when the winding is excited);
3. Since the accuracy of each step is 3% to 5%, and the error of one step will not be accumulated to the next step, it has better position accuracy and motion repeatability;
4. Excellent start-stop and reverse response;
5. Since there is no brush, the reliability is high, so the life of the motor only depends on the life of the bearing;
6. The response of the motor is only determined by the digital input pulse, so open-loop control can be used, which makes the structure of the motor relatively simple and the cost is controlled;
7. Only by connecting the load directly to the shaft of the motor can also rotate synchronously at very low speed.
8. Since the speed is proportional to the pulse frequency, it has a relatively wide speed range.



Electrical Specification Of Hybrid Stepper Motor

Product Name
Hybrid Stepper Motor
Step Accuracy
± 5%
Dielectric Strength
500V AC 1minute
Ambient Temperature
-20℃~50℃
Insulation resistance
100MΩ Min.500V DC
Step Angle
0.9°
Lead wire
6
Voltage (V)
12
Current (A/Phase)
0.38
Holding Torque (Kg.cm)
5.5 Kg.cm




Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 0


Mechanical Dimension Of Hybrid Stepper Motor

Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 1



Market Range of Hetai

Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 2

Hetai also sends its products to the USA, Europe, Southeast Asia, and all-around China.

From China to Overseas
Europe:France,Germany,Italy,Spain, Norway etc.
North America: USA,Canada



Hetai's Customers

Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 3



A variety of types of stepper motors are available for you to choose, support customization.

Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 4



Product Range Of Hetai

Our main products are Stepper Motor, Planetary Gearbox& Gearbox Motor, Brushless DC Motor, Servo Motor.

Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 5

ChangZhou Hetai Motors is an experienced motor manufacturer. For more than 20 years, Hetai dedicates to provide professional electrical integration design and automation strategies for customers. We have variable manufacturing equipment, such as assembly line, Automatic cylindrical grinder and CNC machining centers as well.



Hetai reduction gearbox

Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 6



Silent Room

Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 7

The noise of the motor can be tested in the silent room to make the motor run quietly.



High Quality Material
Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 8

Stator Winding Machine
Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 9Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 10
Hetai introduced a large number of professional equipment, which greatly improved the production efficiency.


CNC Center

Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 11Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 12Nema23 Hybrid Micro Stepping Motor 57BYGHM203-04 57mm 13



Packing&Delivery

Changzhou Hetai Motor And Electric Appliance Co., Ltd. factory production line 16

Changzhou Hetai Motor And Electric Appliance Co., Ltd. factory production line 17

Strictly palletizing and packaging to ensure that the motor will be delivered to the customer in good condition
