PG52A-PM-ST Powder Metallurgy Straight Teeth Planetary Reducer Gearbox 52mm Dia

Name: PG52A-PM-ST Powder Metallurgy Straight Teeth Planetary Reducer Gearbox 52mm Dia
Brand: Changzhou Hetai Motor And Electric Appliance Co., Ltd.
SKU: PG52A-PM-ST
Availability: InStock

Brand Name:	Hetai
Model Number:	PG52A-PM-ST
MOQ:	50
Price:	USD
Delivery Time:	28-31
Payment Terms:	L/C, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE ROHS ISO

Product Name:

Planetary Gearbox

Material:

Powder Metallurgy

Structure:

All-in-one

Type Of Teeth:

Straight Teeth

Reduction Ratio:

Customization

Rated Tolerance Torque（N.m）:

2/8/16

Momentary Tolerance Torque （Nm）:

6/25/50

Efficiency:

90%/80%/72%

Gearbox Length(mm):

46.2/58.5/70.8

Number Of Gear Trains:

1/2/3

Packaging Details:

Carton with Inner Foam Box, Pallet

Supply Ability:

5000pcs/month

Highlight:

Planetary Reducer Gearbox 52mm

Powder Metallurgy Planetary Reducer

Customized Planetary Reducer Gearbox

Product Description

PG52A-PM-ST Powder Metallurgy 52mm dia Straight Teeth Planetary Reducer Gearbox

Advantages of Planetary Gearboxes
1. Planetary reducer ensures flexible and reliable power transmission system
2. Planetary gearbox with multiple speed ratios and long service life
3. The planetary gearbox is small in size and light in weight
4. Unique high power density design of planetary gearbox

Mechanical Dimension

PG52A-PM-ST Powder Metallurgy Straight Teeth Planetary Reducer Gearbox 52mm Dia 0

Gearbox Specification:

Reduction Ratio	Exact Reduction Ratio	Rated Tolerance Torque (Nm)	Momentary Tolerance Torque (Nm)	Efficiency(%)	Length (mm)	Weight (g)	Number of gear trains
1/4.1	1/4.1	2.0	6.0	90%	46.2	/	1
1/6.0	1/6.0
1/8.1	1/8.1
1/17.0	1/17.0	8.0	25.0	80%	58.5	/	2
1/24.8	1/24.8
1/33.6	1/33.6
1/36.0	1/36.0
1/48.8	1/48.8
1/66.3	1/66.3
1/70.2	1/70.2	16.0	50.0	72%	70.8	/	3
1/102.1	1/102.1
1/138.5	1/138.5
1/148.5	1/148.5
1/201.5	1/201.5
1/273.3	1/273.3
1/216.0	1/216.0
1/293.0	1/293.0
1/397.6	1/397.6
1/539.4	1/539.4

Different reduction ratio, torque, weight and length.

Product Range

Right Angle Gearbox

PG52A-PM-ST Powder Metallurgy Straight Teeth Planetary Reducer Gearbox 52mm Dia 2

L type gearbox

Worm Gearbox

Engineering plastic gearbox: low cost and low noise

PG52A-PM-ST Powder Metallurgy Straight Teeth Planetary Reducer Gearbox 52mm Dia 8

Powder metallurgy gearbox:long life and low noise

PG52A-PM-ST Powder Metallurgy Straight Teeth Planetary Reducer Gearbox 52mm Dia 9

Zinc alloy gearbox: low cost

PG52A-PM-ST Powder Metallurgy Straight Teeth Planetary Reducer Gearbox 52mm Dia 11

High-quality Raw Materials

​
Gearbox Material Placement

Gearbox Assembled
